200kW commercial energy storage system
Product Introduction
GBE Battery offers high-performance 200KW/250KW Energy Storage Systems, designed to meet the growing demand for efficient energy storage solutions across commercial, industrial, and large-scale applications. Our lithium-ion battery systems provide long-lasting, reliable, and eco-friendly power storage, making them ideal for businesses looking to optimize energy consumption, reduce operational costs, and enhance energy security.
These advanced storage systems are built to handle high-capacity energy demands, offering scalability and flexibility for energy management. Whether you're looking to store energy for later use, stabilize power grids, or integrate renewable energy sources, GBE Battery's energy storage solutions are the perfect choice.
This 48V 100Ah lithium battery pack is designed for communication base station applications. It can provide long-term and stable power supply for base stations and is suitable for remote and unstable power grid environments. It has the characteristics of high energy density, light weight, long life and high safety, and is an ideal alternative to traditional lead-acid batteries.
Product Advantage
High Energy Density and Long Lifespan
The 200KW/250KW Energy Storage Systems feature high energy density, ensuring efficient power storage and long-lasting performance. With up to 5000 charge-discharge cycles, these batteries offer a significantly longer lifespan compared to traditional lead-acid batteries.
Fast Charging and High Discharge Rates
Our energy storage systems are designed for rapid charging and high discharge rates, allowing for quick response to peak demand periods and reducing downtime.
Intelligent Battery Management System (BMS)
Equipped with an advanced Battery Management System (BMS), GBE Battery’s energy storage systems monitor and manage the battery's state of charge, temperature, and health, optimizing performance and ensuring safe operation.
Reliable and Safe Operation
GBE Battery’s storage systems are built to meet international safety standards, with multiple protective features like overcharge, over-discharge, short circuit, and thermal protection, ensuring reliable operation even in challenging environments.
Eco-Friendly and Sustainable
Our lithium-ion energy storage systems are designed with sustainability in mind. With a lower carbon footprint, minimal maintenance needs, and recyclable components, they contribute to a greener energy future.
Scalable Design
The 200KW/250KW energy storage systems are scalable, allowing users to expand capacity as needed to meet changing energy demands, providing a future-proof solution for growing businesses.
Technical Parameters
200kW Commercial Energy Storage System Technical Sheet | ||
200kW Commercial Energy Storage System | 100kW/215kwh liquid cooling outdoor cabinet | 100kW/215kwh air-cooled outdoor cabinet |
Dimensions (width*depth*height) | 1480mm*1344mm*2086mm | 1810mm*1000mm*2500mm |
Weight | 2.63t | 2.68t |
Maximum cycle efficiency | 90% | 89% |
Protection level | IP55 | IP55 |
Corrosion resistance level | C3 | C3 |
Operating temperature range | -20~+50℃ (>45℃ derating) | -20~+50℃ (>45℃ derating) |
Operating humidity range | 0~95% (no condensation) | 0~95% (no condensation) |
Maximum operating altitude | 3000m | 3000m |
Temperature control method | Liquid cooling | Air cooling |
Fire protection method | Gas fire protection | Gas fire protection |
Auxiliary power supply | External power supply | External power supply |
Communication method | Ethernet | Ethernet |
Communication protocol | Modbus TCP | Modbus TCP |
Certification standard | GB/T 36276、GB/T 34131、GB/T 34120 | GB/T 36276、GB/T 34131、GB/T 34120 |
DC side parameters | ||
Cell type | LFP 3.2V/280Ah | LFP 3.2V/280Ah |
Grouping method | 1P240S | 1P240S |
System nominal capacity | 215kWh | 215kWh |
System rated voltage | 768Vdc | 768Vdc |
System voltage range | 672 ~876Vdc | 672 ~876Vdc |
AC side parameters | ||
Rated power | 100kW | 100kw |
Grid rated voltage | 380Vac | 380Vac |
Grid voltage range | 320~460Vac | 320~460Vac |
Grid rated frequency | 50Hz | 50Hz |
Grid frequency range | 45~55Hz | 45~55Hz |
Total current distortion rate | <3%(rated power) | <3%(rated power) |
DC component | <0.5% | <0.5% |
Isolation method | No isolation | No isolation |
Wiring method | 3W/N/PE | 3W/N/PE |
Product Uses
Commercial Energy Storage
The 200KW/250KW Energy Storage Systems are ideal for businesses and commercial properties, enabling peak shaving, load shifting, and demand response. Store energy during off-peak hours and use it during peak times to save on energy costs and improve energy efficiency.
Renewable Energy Integration
Integrate solar or wind energy with ease. Our energy storage systems store excess renewable energy generated during the day or windy periods, ensuring that businesses can access clean, renewable power whenever needed.
Grid Stabilization and Backup Power
GBE Battery’s energy storage systems provide grid stabilization services, helping balance supply and demand on the grid. Additionally, they offer backup power for critical infrastructure like hospitals, data centers, and factories in case of power outages.
Telecom Base Stations
Ensure uninterrupted power supply to telecom base stations. Our energy storage systems provide backup power to telecom infrastructure, reducing the risk of downtime and improving operational reliability.
Industrial Energy Solutions
For industries with high energy demands, such as manufacturing or warehouses, our 200KW/250KW energy storage solutions provide the necessary power to keep operations running smoothly and efficiently, even during grid fluctuations.
FAQ
1. What is an energy storage system?
An energy storage system is a setup used to store electricity for later use. This system helps manage energy demand, provides backup power during outages, and integrates with renewable energy sources to ensure continuous power supply.
2. What are the main applications for the 200KW/250KW energy storage systems?
Our 200KW/250KW energy storage systems are suitable for commercial and industrial use, telecom base stations, grid stabilization, renewable energy integration, and backup power solutions.
3. How long do the 200KW/250KW batteries last?
GBE Battery’s 200KW/250KW lithium-ion storage systems have a lifespan of 5000+ charge/discharge cycles, ensuring long-term, reliable performance over the years.
4. How fast do the energy storage batteries charge?
Our 200KW/250KW energy storage batteries feature fast-charging technology, enabling them to store energy quickly and efficiently, reducing downtime.
5. What are the safety features of GBE Battery's energy storage systems?
Our systems are equipped with advanced thermal management, overcharge protection, and battery management systems (BMS), which help regulate the temperature, voltage, and current, ensuring safe and efficient operation.
6. Are the 200KW/250KW energy storage systems environmentally friendly?
Yes, GBE Battery’s 200KW/250KW energy storage systems are designed with sustainability in mind. They support renewable energy and have low carbon emissions, making them an eco-friendly solution for energy storage.
7. How do I install the 200KW/250KW energy storage system?
Installation is straightforward, and GBE Battery provides expert support during setup. We offer detailed instructions and assistance to ensure proper installation, system integration, and functionality.
8. Can I scale the 200KW/250KW system for larger energy needs?
Yes, our energy storage systems feature modular designs, allowing for easy scaling. You can expand your storage capacity as your energy demands grow, without replacing the entire system.
