In an evolving world where energy efficiency and reliability define industrial success, the REPT RP280 280Ah LiFePO4 Battery Cell emerges as a trusted power source for modern energy demands. Manufactured by REPT, a leading name in lithium iron phosphate (LiFePO4) technology, this cell balances high energy density, safety, and longevity, making it an ideal candidate for various applications—from electric vehicles and energy storage systems (ESS) to industrial-grade equipment and telecom backup solutions.
With a typical voltage of 3.2V, 280Ah capacity, and a robust cycle life of up to 6000 cycles, the RP280 cell is engineered for long-term usage with minimal degradation. Its versatile performance across temperature ranges and high discharge capabilities makes it a flexible component for high-stakes industrial environments.
Parameter
Details
Manufacturer | REPT |
Model No. | RP280 |
Chemistry | LiFePO4 (Lithium Iron Phosphate) |
Nominal Voltage | 3.2V |
Nominal Capacity | 280Ah |
Energy | ~896Wh |
Internal Resistance | ≤0.3mΩ |
Cycle Life | ≥6000 cycles (@80% DOD, 25℃) |
Standard Charge/Discharge Current | 0.5C / 0.5C |
Max Continuous Charge/Discharge | 1C / 1C |
Pulse Charge/Discharge (30-60s) | 2C / 2C |
Charge Cut-off Voltage | 3.65V |
Discharge Cut-off Voltage | 2.5V (>=0℃), 2.0V (<0℃) |
Recommended SOC Window | 10% ~ 90% |
Charging Temp Range | 0℃ ~ 50℃ |
Discharging Temp Range | -30℃ ~ 55℃ |
Short-Term Storage Temp (<1 Month) | -30℃ ~ 60℃ |
Long-Term Storage Temp (<1 Year) | -10℃ ~ 28℃ |
Storage Humidity | <95% RH |
Dimensions (L x W x H) | 204.4 x 71.7 x 174 mm |
Weight | ~5.4kg |
Certifications | UL, MSDS, UN38.3, CE |
With a nominal energy of approximately 896Wh, the RP280 cell is optimized for systems requiring large-scale energy in a compact format. Its standard prismatic casing allows for seamless module integration with high packaging efficiency.
Achieving up to 6000 cycles at 80% DOD, this cell offers long-term performance and low total cost of ownership, critical for applications like solar storage and off-grid power systems.
With a discharge range of -30℃ to 55℃, the RP280 battery cell performs reliably in extreme climates. It is ideal for outdoor ESS cabinets, telecom base stations, or cold chain logistics.
The cell supports up to 2C pulse charge/discharge, meeting the needs of high-draw equipment such as forklifts, EVs, and industrial robotics.
REPT’s RP280 adheres to international safety standards with UL, UN38.3, MSDS, and CE certifications. LiFePO4 chemistry ensures excellent thermal stability and reduced fire risk.
Used in conjunction with solar inverters, RP280 cells allow users to store excess PV energy and reduce grid dependence. Whether wall-mounted, rack-mounted, or cabinet-based, the cell's high capacity ensures day-to-night autonomy.
Electric forklifts, trucks, buses, and airport trolleys benefit from the RP280’s high discharge rates, fast charging compatibility, and operational consistency under variable loads.
Telecommunication base stations and server rooms rely on battery backup. RP280 cells ensure seamless energy support during outages, with high reliability and fast switchover response.
With its compact design and ability to operate in varying environmental conditions, the RP280 is suitable for off-grid, marine, and mobile energy applications.
Automated Guided Vehicles (AGVs), warehouse robotics, and smart logistics platforms require robust battery packs—RP280 cells meet these needs efficiently.
At GBE Battery, we offer tailor-made solutions built around the REPT RP280 cells. Whether for stationary ESS, EV packs, or portable power stations, our engineering team ensures that every project meets performance, safety, and regulatory goals.
Voltage Options: 12V, 24V, 48V, 96V, 192V...
BMS Integration: Smart BMS with active/passive balancing, CAN/RS485/RS232 communication
Cooling Systems: Natural ventilation, active air cooling, or liquid cooling
Enclosures: IP55/IP67-rated metal cabinets, plastic housings, and modular cases
Communication Protocols: CANBus, Modbus, Bluetooth, WiFi
Safety Protections: Over-voltage, under-voltage, over-temp, short circuit, and cell balancing
✅ Original A-grade Cells with Factory Test Reports
✅ Competitive Prices and Transparent Supply Chain
✅ Short Lead Times with Flexible MOQ
✅ Engineering & Technical Support for OEM/ODM Projects
✅ Compliance with Global Safety Regulations (UL, UN38.3, CE)
✅ Safe Global Shipping and After-sales Service
We not only supply RP280 cells—we deliver complete lithium battery solutions.
If you're a system integrator or OEM, we provide documentation and consulting support for:
Thermal simulation and pack architecture
BMS configuration
Pack voltage and current optimization
Series-parallel configuration (e.g., 16S1P, 32S1P)
Certifications and safety test reports for final system
Application | Configuration | System Voltage | Energy |
Home ESS (5kWh) | 1P4S | 12.8V | 3.5kWh |
Residential ESS (10kWh) | 1P16S | 51.2V | ~13.8kWh |
Commercial ESS (100kWh) | 2P32S | 102.4V | ~179kWh |
EV Bus Battery | 4P32S | 102.4V | ~358kWh |
Ready to start your project? GBE Battery provides quick support for quotations, datasheets, and engineering evaluation.
Email: info@gbebattery.com
Website: www.gbebattery.com
Phone/WhatsApp: +86-156 5600 5075 (Add contact here)
You can also send us your battery project specifications (voltage, capacity, size constraints, interface, and application) and our team will recommend the most suitable configuration.
RP280 Official Datasheet (PDF)
Test Report (Cycle Life, Internal Resistance, Capacity Retention)
CAD Drawings & Dimensional Files (DWG/STEP)
UN38.3 Transport Certification
BMS Communication Protocol Files
The REPT RP280 280Ah LiFePO4 battery cell is the foundation for powerful, scalable, and safe energy solutions across sectors. Backed by REPT’s cell manufacturing expertise and GBE Battery’s engineering strength, your lithium power solution is in expert hands.
