Product Description
Product Advantage
High energy density and long battery life
Single cell capacity of 105Ah optimizes energy storage efficiency and provides longer battery life for the device.
Excellent cycle life
Supports more than 3,500 cycles (80% DOD), significantly reducing long-term use costs.
Excellent consistency
The cell internal resistance, voltage and capacity are highly consistent, which is convenient for large-scale series and parallel use, and is suitable for the modular design of energy storage and power systems. Suitable for large-scale modular applications.
Technical Parameters
| 2.1 Basic Specifications and Parameters Table 2 Basic specifications and parameters | ||
| Items | Specification | Notes |
| Nominal Capacity | 105.0Ah | 0.5C/0.5C,25℃±2℃,2.5V~3.65V, Fresh cell |
| Nominal Energy | 336.0 Wh | |
| Nominal Voltage | 3.2V | 0.5C discharge,25℃±2℃,2.5V~3.65 V 0.5C |
| End-off-charge Voltage | 3.65V | / |
| End-off-discharge Voltage | 2.5V(T>0℃) 2.0V(T≤0℃) | / |
| Standard Charging Current | 52.5A | 0.5C |
| Maximum Instantaneous Charging Current | 2C | 30s,≤80%SOC,25℃±2℃ |
| Standard Discharging Current | 52.5A | 0.5C |
| Model | LF105 | Specification No. | PBRI-LF105-D06-01 | Version | E | |||
| Mmtimukn Imotntaneous Dischaaging Coarremt | 3C | 30m,≥30%SOC,25℃±2℃ | ||||||
| Initial IR | 0.32mΩ±0.05m | AC,1 kHz,19%~40% SOC, Fresh cell | ||||||
| Dinect Current Renimnmce (DCR) | ≤1.8mΩ | 25℃,50% SOC,1C,10a, Fresh cell | ||||||
| Weight | 1980g±60g | / | ||||||
| Dimension (With Insulation Film） | Terminal Heighr | 200.50mm±0.50mm | With Terurital | |||||
| Can-top Height | 195.50mm±0.50mm | Without Terminal | ||||||
| Length | 130.30mm=0.50man | / | ||||||
| Thicloness | 36.35mmn±050mm | (300 kgf±20 kgf comprestion force, Delivery SOC) | ||||||
| Center Dislance between Poles | 67mm=1mm | / | ||||||
| Opemnion Temperafure | Charge Temperature | -10℃~65℃ | / | |||||
| Discharge Temperature | -35°C~65℃ | / | ||||||
| Storage Temperature | 3 moolhs | 0℃~35℃ | Delivery SOC | |||||
| 1month | -20℃~45℃ | |||||||
| Swelling force a EOL | ≤30000 N | 80% SOH | ||||||
Product Uses
| Brand NName | EVE |
| Model Number | LF105 |
| Battery Type | LiFePO4 |
| Product name | EVE LF105 3.2V 105Ah Forklift RV Engineering power cells |
| Application | Electric energy storage、Household energy storage、Ship energy storage、Construction Machinery、Construction power、Electric forklifts、Electric Loader、RV、Engineering power、Telecom energy storage |
| Capacity | 105Ah |
| Voltage | 3.2V |
| Standard Charge-discharge rate | 0.5C(P) |
| Cycling Performance | 4000 Cycles (25℃)、2000 Cycles (45℃) |
| Charging Temperature | 0℃~65℃ |
| Discharging Temperature | -35℃~65℃ |
| Storage Temperature | 0℃C~35℃ |
| Certificate | ESG、CE、RoHS、UN38.3、MSDS、UL、IEC、ATEX、Reach、GB/T、 BIS... |
