IFR32135-15Ah
GOTION/GUOUXUAN
Product Description
Features
High Energy Density
One of the standout features of Guoxuan 15Ah cells is their high energy density, which ensures that these cells store more energy in less space. This makes them ideal for electric vehicles, where space and weight are crucial considerations. A higher energy density also means more range for electric vehicles on a single charge.
Long Cycle Life
Guoxuan 15Ah battery cells are built for durability and longevity, offering a long cycle life of up to 2,000 cycles or more, depending on usage. This is a crucial factor for EV manufacturers and energy storage systems, as a longer lifespan reduces the total cost of ownership and minimizes maintenance needs over time.
Fast Charging Capabilities
Fast charging is a critical consideration for both electric vehicles and home energy storage systems. The Guoxuan 15Ah cell supports high-speed charging, reducing downtime and increasing operational efficiency.
Enhanced Safety Features
Safety is a top priority when it comes to battery technology, and Guoxuan takes it seriously. The 15Ah cells come with built-in overcharge protection, temperature regulation, and short-circuit protection to ensure the safety of both the user and the system. This is especially important in high-stress applications like EVs and grid-connected energy storage systems.
Eco-Friendly and Sustainable
Guoxuan focuses on creating batteries that are not only high-performing but also eco-friendly. These lithium-ion cells contribute to reducing the reliance on fossil fuels and promote cleaner energy alternatives. By utilizing renewable energy sources in EVs and storage systems, Guoxuan’s 15Ah battery cells play a crucial role in the global shift towards sustainability.
Technical Parameters
Item | Specifications | Remarks |
4.1 Appearance | No cracks, scratches, deformations, stains, | |
4.2 Dimensions | φ33.4mm*140.0mm (including pole and outer film) | See Appendix A for details |
4.3 Weight | 267g±4.0g | |
4.4 Nominal voltage | 3.2V | 0.33C |
3.1V | 1C | |
4.5 AC Internal Resistance | 1.5mΩ≤R≤3mΩ | Standard deviation of AC internal |
4.6 DC Internal Resistance | <8mΩ | Room temperature, 50%SOC |
4.7 Rated capacity | ≥15.8Ah | 0.33C |
≥15Ah | 1C | |
4.8 Operating Voltage | 2.0V~3.65V | room temperature |
4.9 Mass Energy Density | ≥189Wh/kg | 0.33C |
≥179Wh/kg | 1C |
Product Uses
Electric Vehicles (EVs)
The automotive industry is rapidly transitioning to electric power, and Guoxuan 15Ah battery cells are a perfect fit for EV applications. With a high capacity, long lifespan, and quick charging times, these cells provide the power and reliability needed to support a variety of electric vehicle models, including cars, buses, and trucks.
Energy Storage Systems (ESS)
Home and commercial energy storage systems are increasingly using Guoxuan 15Ah cells to store renewable energy for later use. By connecting to solar panels, wind turbines, or the electrical grid, these battery cells store excess energy during periods of low demand and release it when needed, ensuring efficient energy use and reducing reliance on the grid.
Power Tools and Other High-Performance Applications
Guoxuan 15Ah cells are also used in other industries that require high-performance, reliable power. These include power tools, backup power systems, and mobile energy solutions, providing a flexible and scalable power source.
FAQ
What is the Lead Time?
Quantity (pieces) | 1 - 10000 | 10001 - 100000 | > 100000 |
Lead time (days) | 16 | 25 | To be negotiated |
I can not make sure the Gotion 15Ah can suit my battery pack?
First we provide the cells in A level, so work parameters should be ok, about the size best check with your engineers. Second we also can provide the pack for you, and make sample for you. Details please contact our sales man.
How do i trust your quality?
yes, The current market confuses many customers. There are few customers who really understand the quality in detail and can test the quality independently. I suggest ordering in small batches. At the same time, we provide the original quality inspection data, and the battery cell code is reflected.
